  • Trackstar Round Belt Guides
  • Trackstar Round Belt Guides - dim
1 - 24 of 24 | Results Per Page | View | Unit of Measure
1
CAD help Compare Items
Clear Filter

Belt Cross Section

Part Number

Material

Belt Cross Section

Channel Type

A

B

D

H

N/A Galvanized N/A 4mm, 5mm, 3/16” N/A C3 N/A 0.59 in N/A 0.79 in N/A 0.80 in N/A 0.13 in
N/A Galvanized N/A 6mm, 1/4” N/A C3 N/A 0.59 in N/A 0.79 in N/A 0.80 in N/A 0.16 in
N/A Galvanized N/A 7mm, 8mm, 5/16” N/A C3 N/A 0.59 in N/A 0.79 in N/A 0.80 in N/A 0.19 in
N/A Galvanized N/A 9mm, 9.5mm, 3/8” N/A C5 N/A 0.59 in N/A 1.10 in N/A 0.84 in N/A 0.22 in
N/A Galvanized N/A 10mm, 12mm, 12.7mm, 1/2” N/A C5 N/A 0.59 in N/A 1.10 in N/A 0.84 in N/A 0.28 in
N/A Galvanized N/A 13mm, 14mm, 9/16” N/A C5 N/A 0.59 in N/A 1.10 in N/A 0.84 in N/A 0.32 in
N/A Galvanized N/A 15mm, 16mm, 5/8” N/A C5 N/A 0.71 in N/A 1.10 in N/A 0.94 in N/A 0.35 in
N/A Galvanized N/A 18mm, 19mm, 20mm, 3/4” N/A C5 N/A 1.02 in N/A 1.10 in N/A 1.260 in N/A 0.41 in
N/A Stainless Steel N/A 4mm, 5mm, 3/16” N/A C3 N/A 0.59 in N/A 0.79 in N/A 0.80 in N/A 0.13 in
N/A Stainless Steel N/A 6mm, 1/4” N/A C3 N/A 0.59 in N/A 0.79 in N/A 0.80 in N/A 0.16 in
N/A Stainless Steel N/A 7mm, 8mm, 5/16” N/A C3 N/A 0.59 in N/A 0.79 in N/A 0.80 in N/A 0.19 in
N/A Stainless Steel N/A 9mm, 9.5mm, 3/8” N/A C5 N/A 0.59 in N/A 1.10 in N/A 0.84 in N/A 0.22 in
N/A Stainless Steel N/A 10mm, 12mm, 12.7mm, 1/2” N/A C5 N/A 0.59 in N/A 1.10 in N/A 0.84 in N/A 0.28 in
N/A Stainless Steel N/A 13mm, 14mm, 9/16” N/A C5 N/A 0.59 in N/A 1.10 in N/A 0.84 in N/A 0.32 in
N/A Stainless Steel N/A 15mm, 16mm, 5/8” N/A C5 N/A 0.71 in N/A 1.10 in N/A 0.94 in N/A 0.35 in
N/A Stainless Steel N/A 18mm, 19mm, 20mm, 3/4” N/A C5 N/A 1.02 in N/A 1.10 in N/A 1.260 in N/A 0.41 in
N/A UHMW N/A 4mm, 5mm, 3/16” N/A C3 N/A 0.59 in N/A 0.79 in N/A 0.80 in N/A 0.13 in
N/A UHMW N/A 6mm, 1/4” N/A C3 N/A 0.59 in N/A 0.79 in N/A 0.80 in N/A 0.16 in
N/A UHMW N/A 7mm, 8mm, 5/16” N/A C3 N/A 0.59 in N/A 0.79 in N/A 0.80 in N/A 0.19 in
N/A UHMW N/A 9mm, 9.5mm, 3/8” N/A C5 N/A 0.59 in N/A 1.10 in N/A 0.84 in N/A 0.22 in
N/A UHMW N/A 10mm, 12mm, 12.7mm, 1/2” N/A C5 N/A 0.59 in N/A 1.10 in N/A 0.84 in N/A 0.28 in
N/A UHMW N/A 13mm, 14mm, 9/16” N/A C5 N/A 0.59 in N/A 1.10 in N/A 0.84 in N/A 0.32 in
N/A UHMW N/A 15mm, 16mm, 5/8” N/A C5 N/A 0.71 in N/A 1.10 in N/A 0.94 in N/A 0.35 in
N/A UHMW N/A 18mm, 19mm, 20mm, 3/4” N/A C5 N/A 1.02 in N/A 1.10 in N/A 1.260 in N/A 0.41 in
